| Kod |
Ölçü(İnç) |
Nominal Çap |
Sıkma Aralığı |
L (mm) |
H(mm) |
M |
sxB |
Trifon |
Kopma Yükü KN |
Çalışma Yükü KN |
| 701016 |
3/8" |
10 |
16-20 |
60.0 |
26.0 |
M6 |
1.0x20 |
7x70 mm |
0.5 |
0.3 |
| 701020 |
1/2" |
15 |
20-24 |
64.0 |
28.0 |
M6 |
1.0x20 |
7x70 mm |
0.8 |
0.5 |
| 701025 |
3/4" |
20 |
25-30 |
69.0 |
31.0 |
M6 |
1.0x20 |
7x70 mm |
1.0 |
0.7 |
| 701032 |
1" |
25 |
32-38 |
77.0 |
35.0 |
M6 |
1.0x20 |
7x70 mm |
1.3 |
0.8 |
| 701040 |
1 1/4" |
32 |
39-46 |
87.0 |
39.0 |
M6 |
1.2x20 |
7x70mm |
1.6 |
1.1 |
| 701050 |
1 1/2" |
40 |
48-53 |
98.0 |
42.5 |
M6 |
1.2x20 |
7x70 mm |
2.0 |
1.3 |
| 701063 |
2" |
50 |
59-66 |
108.0 |
49.0 |
M6 |
1.2x20 |
7x70 mm |
2.5 |
1.7 |
| 701075 |
2 1/2" |
65 |
74-80 |
120.0 |
58.0 |
M6 |
1.5x25 |
7x70 mm |
3.3 |
2.2 |
| 701090 |
3" |
80 |
87-94 |
145.0 |
64.0 |
M6 |
1.5x25 |
7x70 mm |
4.0 |
2.7 |
| 701100 |
3 1/2" |
102-111 |
102-111 |
161.0 |
72.0 |
M6 |
1.5x25 |
7x70 mm |
4.0 |
2.7 |
| 701110 |
4" |
100 |
108-116 |
170.0 |
77.0 |
M6 |
1.5x25 |
7x70 mm |
5.0 |
3.3 |
| 701115 |
4 1/2" |
120-129 |
120-129 |
191.0 |
84.0 |
M6 |
2.0x25 |
7x70 mm |
5.2 |
3.6 |
| 701125 |
5" |
125 |
120-129 |
135-148 |
200.0 |
M6 |
2.0x25 |
7x70 mm |
6.3 |
4.2 |
| 701140 |
5 1/2" |
149-156 |
149-156 |
222.0 |
96.0 |
M6 |
2.0x25 |
7x70 mm |
6.5 |
4.6 |
| 701150 |
6" |
150 |
162-168 |
230.0 |
102.5 |
M6 |
2.0x25 |
7x70 mm |
7.5 |
5.0 |
