| Kod |
Ölçü(İnç) |
Nominal Çap |
L (mm) |
H (mm) |
sxB |
Qd mm |
Kopma Yükü KN |
Çalışma Yükü KN |
| 704020 |
1/2" |
28 |
51.5 |
36.5 |
1X25 |
10.5 |
6 |
1.5 |
| 704025 |
3/4" |
30 |
53.5 |
37.5 |
1X25 |
10.5 |
6 |
1.5 |
| 704032 |
1" |
36 |
65.5 |
46.5 |
1X25 |
10.5 |
6 |
1.5 |
| 704040 |
1 1/4" |
46 |
79.9 |
55.7 |
1.2X25 |
10.5 |
11 |
1.5 |
| 704050 |
1 1/2" |
52 |
85.9 |
58.7 |
1.2X25 |
10.5 |
11 |
1.5 |
| 704063 |
2" |
66 |
99.9 |
65.7 |
1.2X25 |
10.5 |
11 |
1.5 |
| 704075 |
2 1/2" |
78 |
116 |
75.5 |
1.5X25 |
10.5 |
16 |
3.9 |
| 704090 |
3" |
92/td>
| 132 |
84.5 |
1.5X25 |
10.5 |
16 |
3.9 |
| 704110 |
4" |
116/td>
| 167.5 |
107.5 |
2X25 |
10.5 |
19 |
3.9 |
| 704125 |
5" |
142/td>
| 200 |
126.5 |
2.5X25 |
13 |
22 |
7.5 |
| 704150 |
6" |
170/td>
| 238 |
150.5 |
2.5X25 |
13 |
22 |
7.5 |
| 704160 |
8" |
222/td>
| 311.5 |
197.5 |
3x30 |
17 |
30 |
13 |
| 704175 |
10" |
275/td>
| 384.5 |
244 |
3x30 |
17 |
30 |
13 |
| 704200 |
12" |
324/td>
| 470 |
310 |
3x30 |
17 |
30 |
13 |
